12-fiber Breakout Cable
Fiber Parameters
|
No. |
Items |
unit |
Specification |
|
|
10G-300 |
||||
|
1 |
Core Diameter |
μm |
50.0±2.5 |
|
|
2 |
Cladding Diameter |
μm |
124.8±1.0 |
|
|
3 |
Core Non-Circularity |
% |
≤5.0 |
|
|
4 |
Cladding Non-Circularity |
% |
≤1.0 |
|
|
5 |
Core-Cladding Concentricity Error |
μm |
≤1.0 |
|
|
6 |
Coating Diameter |
μm |
245±7 |
|
|
7 |
Coating Non-Circularity |
% |
≤6.0 |
|
|
8 |
Cladding-Coating Concentricity Error |
μm |
≤12.0 |
|
|
9 |
OFL Bandwidth |
850nm |
MHz·km |
≥1500 |
|
1300nm |
MHz·km |
≥500 |
||
|
10 |
Effective Modal Bandwidth |
850nm |
MHz·km |
≥2000 |
|
1300nm |
MHz·km |
≥500 |
||
|
11 |
Attenuation Coefficient |
850nm |
dB/km |
≤3.0 |
|
1300nm |
dB/km |
≤1.0 |
||
Cable Parameters
|
Items |
Specifications |
|
|
Fiber Count |
12 |
|
|
Tight-buffered Fiber |
Dimension |
850µm±50µm |
|
Material |
LSZH |
|
|
Color |
White |
|
|
Simplex Cable |
Dimension |
2.0mm±0.1mm |
|
Material |
LSZH |
|
|
é¢č² Color |
Aqua |
|
|
Strength Member |
Kevlar |
|
|
Printing Marks |
ć1ćļ½ć12ć |
|
|
Central Strength Member |
Diameter |
5.7mm±0.1mm |
|
Material |
FRP+LSZH |
|
|
Color |
Aqua |
|
|
Outer Jacket |
Dimension |
12.5mm±0.5mm |
|
Material |
LSZH |
|
|
Color |
Aqua |
|
Mechanical and Environmental Characteristics
|
Items |
Unite |
Specifications |
|
Tensionļ¼Long Termļ¼ |
N |
500 |
|
Tensionļ¼Short Termļ¼ |
N |
1000 |
|
Crushļ¼Long Termļ¼ |
N/10cm |
300 |
|
Crushļ¼Short Termļ¼ |
N/10cm |
1000 |
|
in. Bend Radiusļ¼Dynamicļ¼ |
mm |
20D |
|
Min. Bend Radiusļ¼Staticļ¼ |
mm |
10D |
|
Installation Temperature |
ā |
-10ļ½+50 |
|
Operating Temperature |
ā |
-20ļ½+60 |
|
Storage Temperature |
ā |
-20ļ½+60 |
